Leica Macro-Elmar-M 90mm f/4 Black Anodized
€ 3.650,00 (incl. VAT)
The Macro-Elmar-M 90 mm f/4 can be used as a compact 90 mm telephoto lens or, in combination with the Leica Macro-Adapter-M, for macro shots up to a magnification of 1:2. Either way, the lens provides an incredibly high imaging performance.
-
Description
-
Additional information
-
Specifications
-
What's in the Box
Leica Macro-Elmar-M 90mm f/4
Top Performance in Micro Format
Creating proximity
The Macro-Elmar-M 90 mm f/4 can be used as a compact 90 mm telephoto lens or, in combination with the Leica Macro-Adapter-M, for macro shots up to a magnification of 1:2. Either way, the lens provides an incredibly high imaging performance.
Without the adapter, the Leica Macro-Elmar-M 90 mm f/4 is an extremely versatile telephoto lens – for example, for portraits with shallow depth of field and in travel photography for capturing details in landscapes. For reportage photography, the Leica Macro-Elmar-M 90 mm f/4 allows photographers to capture discreet shots at a greater distance from the subjects. The Leica Macro-Elmar-M 90 mm f/4 is a compact and lightweight alternative to existing Leica M-Lenses of this focal length. When not in use, the lens can be collapsed to save valuable space in the camera bag.
The new macro solution for the Leica M (Typ 240):
The Leica Macro-Elmar-M 90 mm f/4 and the Macro-Adapter-M form together a convenient solution for close distance photography using the live view function of the Leica M (Typ 240).
The adapter is designed to be mounted between the camera and the Leica Macro-Elmar-M 90 mm f/4. Its integrated helical screw system allows a variable extension of the lens of between 18 and 30 mm and thus enables the variation of the reproduction ratio. When mounted on the adapter, the Leica Macro-Elmar-M 90 mm f/4 can also be used in its collapsed position for exposures up to infinity. Thanks to a new locking function, this allows photographers to set any distance from 41 cm (reproduction ratio 1:2) to infinity without having to dismount the adapter.
The new macro-adapter-M
As the Macro-Adapter-M is also compatible with other M lenses, it offers Leica M photographers an even wider range of opportunities for creative composition and additional variety in reportage portfolios. With Leica lenses from 50mm and longer, it enables macro photography up to a reproduction ratio of 1:2 and, with wide-angle lenses, even larger ratios.
The essentials:
- Diagonal picture angle: 27 °
- Working range: 0.8 m to infinity
- Biggest scale: 1: 6,8
- Number of lenses/groups: 4/4
- Length * 1: 59 mm
- Weight * 1: 230 g
- Lens hood: attachable
- Filter/filter thread: E39
- Made in Germany
| Camera System | M System |
|---|---|
| Colour | Black |
Specifications
-
Angle of view (diagonal, horizontal, vertical):
27° / 23° / 15° (M8: 20° / 17° /11°)
-
Optical design
-
Number of lenses/groups:
4 / 4
-
Focal length:
90.0 mm
-
Position of entrance pupil (from bayonet flange):
22 mm
-
Focusing range:
0,8 m to infinity
-
Distance setting
-
Scales:
Combined meter/feet graduation
-
Smallest object field:
169 x 244 mm (Adapter 72 x 108 mm) M8:122 x 183 mm (Adapter: 36 x 54 mm)
-
Largest reproduction ratio:
Approx. 1:6,7
-
Aperture
-
Setting/Function:
Prefix with click-stops, half steps, click-stop
-
Lowest value:
22
-
Bayonet:
Leica M quick-change bayonet with 6 bit lens identification bar code for digital M models
-
Filter mount:
Internal thread for screw-in type filters E39, non-rotating lens mount
-
Lens hood:
Separate metal lens hood, can be attached in reverse for storage
-
Dimension and weight
-
Length:
59 mm (lens extended, in working position), 41 mm (lens collapsed, in storage position)
-
Largest diameter:
52 mm
-
Weight:
Approx. 230 g
What's in the Box
- Leica Macro-Elmar-M 90mm f/4 Lens
- Leica Lens Hood for 90mm f/4-M and 135mm f/3.4-M Lenses
- Front Lens Cap
- Leica Rear Lens Cap for M-Mount Lenses
- Leather Lens Bag
- Limited 3-Year Manufacturer Warranty
